The Superlative Arms patented “Bleed Off”, direct impingement, gas block for the AR15 platform adjusts the gas flow by bleeding the gas out of the block instead of restricting the flow like conventional adjustable blocks. Results: The pressure used in the block is reduced only to the amount required to drive the bolt carrier. The remaining gas / pressure are bled out of the block allowing the system to run much cleaner and cooler. Reduction of felt recoil. Patented adjustment detent is located outside of the block and therefore no contamination. The gas adjustment screw does not restrict the gas flow; therefore there is no erosion or seizing of the screw / no loss of detent due to carbon build up. Although it is removable, we have added a safety mechanism, which stops you from unintentionally backing the screw all the way out. When using SBR’s and / or suppressors the bleed off port allows the excessive pressure to be exhausted out of the block reducing blow back. Data: Gas Block Material: 416 SS Barrel Diameter: 0.625" Weight: 1.34 oz. Length: 1.00" Attachment Type: Clamp on Adjustment: Front of Block Included: Gas Block - Assembled (2) 10-32 x 3/16" Socket Head Cap Screws (1) Gas Tube Roll Pins (1) 3/32 X 6" L-Shaped Hex Keys Installation Instructions & QR code for video tutorial
Entdecke die innovative Lösung für dein AR-15!
Der patentierte „Bleed Off“ Gasblock von Superlative Arms für die AR15-Plattform bietet eine einzigartige Möglichkeit zur Anpassung des Gasflusses. Anstatt den Fluss wie herkömmliche verstellbare Blöcke einzuschränken, lässt dieser Block das Gas ab, was zu einem saubereren und kühleren Betrieb führt.
Produktbeschreibung
Mit diesem Gasblock wird der Druck im Block nur auf das notwendige Maß reduziert, um den Verschluss zu betätigen. Der verbleibende Gasdruck wird aus dem Block abgelassen, was die Rückstoßkraft spürbar verringert. Der patentierte Einstell-Dent befindet sich außerhalb des Blocks, was eine Kontamination verhindert.
- Gas Block Material: 416 SS
- Laufdurchmesser: 0.625"
- Gewicht: 1.34 oz
- Länge: 1.00"
- Befestigungsart: Clamp on
- Einstellung: Vorderseite des Blocks
Der Gasverstellungsschraube schränkt den Gasfluss nicht ein, wodurch Erosion oder Festfressen der Schraube vermieden wird und es keinen Verlust des Dent durch Kohlenstoffablagerungen gibt. Obwohl die Schraube abnehmbar ist, haben wir einen Sicherheitsmechanismus hinzugefügt, der verhindert, dass du die Schraube versehentlich ganz herausdrehst.
Bei der Verwendung von SBRs und/oder Schalldämpfern ermöglicht der Bleed-Off-Port, dass übermäßiger Druck aus dem Block entweichen kann, was den Rückstoß reduziert.
Im Lieferumfang enthalten:
- Gasblock - montiert
- (2) 10-32 x 3/16" Innensechskantschrauben
- (1) Gasrohr-Rollstifte
- (1) 3/32 x 6" L-förmige Innensechskantschlüssel
- Montageanleitung & QR-Code für Videoanleitung
