The Superlative Arms patented “Bleed Off”, direct impingement, gas block for the AR15 platform adjusts the gas flow by bleeding the gas out of the block instead of restricting the flow like conventional adjustable blocks. Results: The pressure used in the block is reduced only to the amount required to drive the bolt carrier. The remaining gas / pressure are bled out of the block allowing the system to run much cleaner and cooler. Reduction of felt recoil. Patented adjustment detent is located outside of the block and therefore no contamination. The gas adjustment screw does not restrict the gas flow; therefore there is no erosion or seizing of the screw / no loss of detent due to carbon build up. Although it is removable, we have added a safety mechanism, which stops you from unintentionally backing the screw all the way out. When using SBR’s and / or suppressors the bleed off port allows the excessive pressure to be exhausted out of the block reducing blow back. Data: Gas Block Material: 416 SS Barrel Diameter: 0.625" Weight: 1.34 oz. Length: 1.00" Attachment Type: Clamp on Adjustment: Front of Block Included: Gas Block - Assembled (2) 10-32 x 3/16" Socket Head Cap Screws (1) Gas Tube Roll Pins (1) 3/32 X 6" L-Shaped Hex Keys Installation Instructions & QR code for video tutorial
Kompakter und innovativer Gasblock für deine AR15!
Der patentierte „Bleed Off“ Gasblock von Superlative Arms für die AR15-Plattform ist eine revolutionäre Lösung, die den Gasfluss anpasst, indem sie das Gas aus dem Block ableitet, anstatt den Fluss wie bei herkömmlichen verstellbaren Blöcken zu beschränken.
Vorteile:
- Reduzierter Druck: Der Druck im Block wird nur auf das erforderliche Minimum reduziert, um den Verschluss zu betreiben.
- Sauberer und kühler Betrieb: Das verbleibende Gas/Druck wird aus dem Block abgeleitet, sodass das System viel sauberer und kühler läuft.
- Verminderter Rückstoß: Spürbare Verringerung des Rückstoßes.
- Patentierter Einstellmechanismus: Dieser befindet sich außerhalb des Blocks, wodurch eine Kontamination verhindert wird.
- Keine Einschränkung des Gasflusses: Der Gasverstellschraube schränkt den Gasfluss nicht ein, was Erosion oder Festfressen der Schraube sowie Verlust des Detents durch Kohlenstoffablagerungen vermeidet.
- Sicherheitsmechanismus: Obwohl der Gasblock abnehmbar ist, haben wir einen Sicherheitsmechanismus hinzugefügt, der verhindert, dass du die Schraube versehentlich ganz herausdrehst.
- Für SBRs und Suppressoren: Der Bleed Off-Port ermöglicht es, übermäßigen Druck abzulassen, wodurch der Rückstoß reduziert wird.
Technische Daten:
- Material des Gasblocks: 416 SS
- Rohrdurchmesser: 0.625"
- Gewicht: 1.34 oz.
- Länge: 1.00"
- Befestigungsart: Clamp on
- Einstellung: Front des Blocks
Im Lieferumfang enthalten:
- Gasblock - Vormontiert
- (2) 10-32 x 3/16" Innensechskantschrauben
- (1) Gasrohr-Rollstifte
- (1) 3/32 X 6" L-förmige Inbusschlüssel
- Montageanleitung & QR-Code für Videoanleitung
