The Superlative Arms patented “Bleed Off”, direct impingement, gas block for the AR15 platform adjusts the gas flow by bleeding the gas out of the block instead of restricting the flow like conventional adjustable blocks. Results: The pressure used in the block is reduced only to the amount required to drive the bolt carrier. The remaining gas / pressure are bled out of the block allowing the system to run much cleaner and cooler. Reduction of felt recoil. Patented adjustment detent is located outside of the block and therefore no contamination. The gas adjustment screw does not restrict the gas flow; therefore there is no erosion or seizing of the screw / no loss of detent due to carbon build up. Although it is removable, we have added a safety mechanism, which stops you from unintentionally backing the screw all the way out. When using SBR’s and / or suppressors the bleed off port allows the excessive pressure to be exhausted out of the block reducing blow back. Data: Gas Block Material: 416 SS Barrel Diameter: 0.625" Weight: 1.37 oz. Length: 1.00" Attachment Type: Solid Gas Adjustment: 30 Locked Positions, Front Of Block Bleed Off Port: Front Of Block Included: Gas Block - Assembled (2) 10-32 x 3/16" Set Screws (1) Gas Tube Roll Pins (1) 3/32 X 6" L-Shaped Hex Keys Installation Instructions & QR code for video tutorial
Verbessere dein AR-15 mit dem innovativen Gasblock!
Der patentierte „Bleed Off“ Gasblock von Superlative Arms für die AR15-Plattform ist eine revolutionäre Lösung, die den Gasfluss anpasst, indem sie das Gas aus dem Block abführt, anstatt den Fluss wie herkömmliche verstellbare Blöcke zu beschränken.
Produktbeschreibung
Durch diese Technik wird der Druck im Block nur auf das notwendige Minimum reduziert, um den Verschluss zu betreiben. Der verbleibende Gasdruck wird aus dem Block abgeleitet, was das System wesentlich sauberer und kühler laufen lässt. Das Ergebnis ist eine spürbare Reduzierung des Rückstoßes.
- Patentiere Einstellmechanismus: Der Einstellungsdetent befindet sich außerhalb des Blocks, wodurch eine Kontamination vermieden wird.
- Gasverstellschraube: Diese schränkt den Gasfluss nicht ein, wodurch Erosion oder Festfressen der Schraube sowie der Verlust des Detents durch Kohlenstoffablagerungen vermieden werden.
- Sicherheitsmechanismus: Obwohl die Schraube abnehmbar ist, haben wir einen Sicherheitsmechanismus hinzugefügt, der verhindert, dass du die Schraube versehentlich ganz herausdrehst.
- Für SBRs und/oder Schalldämpfer: Der Bleed-Off-Port ermöglicht es, übermäßigen Druck aus dem Block abzulassen, wodurch der Rückstoß verringert wird.
Technische Daten
- Material des Gasblocks: 416 SS
- Laufdurchmesser: 0.625"
- Gewicht: 1.37 oz
- Länge: 1.00"
- Befestigungsart: Solid
- Gasverstellung: 30 gesperrte Positionen, Vorderseite des Blocks
- Bleed Off Port: Vorderseite des Blocks
Lieferumfang:
- Gasblock - montiert
- (2) 10-32 x 3/16" Set-Schrauben
- (1) Gasrohr-Rollstifte
- (1) 3/32 x 6" L-förmige Inbusschlüssel
- Montageanleitung & QR-Code für Videoanleitung
